TECHNICAL SPECIFICATIONS
MODEL |
4 MM SERIES |
APPLICATION |
2 FIXED 2 SLIDE |
HEIGHT |
180 cm |
MEASURE RANGE |
130 - 230 |
ADJUSTMENT SHARE |
1,5 cm |
PROFILE THICKNESS |
3 cm |
PROFILE WEIGHT |
0,280 GR/MT |
GLASS |
4MM |
GLASS EDGE CHAMFER |
NONE |
HANDLE |
PLASTIC CHROMAGE |
CHROMAGE COVER |
NONE |
ROLLER |
DERLIN/BRASS |
TECHNICAL DRAWING
TECHNICAL SPECIFICATIONS
MODEL |
4 MM SERIES |
APPLICATION |
2 FIXED 2 SLIDE |
HEIGHT |
150 cm |
MEASURE RANGE |
130 - 230 |
ADJUSTMENT SHARE |
1,5 cm |
PROFILE THICKNESS |
3 cm |
PROFILE WEIGHT |
0,280 GR/MT |
GLASS |
4MM |
GLASS EDGE CHAMFER |
NONE |
HANDLE |
PLASTIC CHROMAGE |
CHROMAGE COVER |
NONE |
ROLLER |
DERLIN/BRASS |
TECHNICAL DRAWING
